Double Glass Bifacial 144cells Solar Panel 455W

Name: b59363d94fc806d1ade95d2e6b60e78b
Uploaded: 2024-07-01T19:36:02+08:00
Description: Product Attributes Model No.: 455M6-24 Brand: HAOXUAN Place Of Origin: China Types

Get Latest Price

Payment Type:

L/C,T/T

Incoterm:

FOB,CFR,CIF

Min. Order:

1 Set/Sets

Transportation:

Ocean,Land,Air

Contact Now

Product Description

Product Attributes
Supply Ability & Additional Information
Packaging & Delivery

< >

Overview

Product Attributes

Brand: HAOXUAN

Supply Ability & Additional Information

Transportation: Ocean,Land,Air

Payment Type: L/C,T/T

Incoterm: FOB,CFR,CIF

Packaging & Delivery

Selling Units:: Set/Sets

Product Attributes

Model No.: 455M6-24

Brand: HAOXUAN

Place Of Origin: China

Types Of: Perc, Half Cell, Bifacial, Double-Glass, All Black

Dimension: 2094*1038*35mm

Supply Ability & Additional Information

Packaging: Standard Exported Pallet

Productivity: 4000pcs/day

Transportation: Ocean,Land,Air

Place of Origin: China

Supply Ability: 2GW/Year

Certificate: CE,TUV, INMETRO, PSI,COC

HS Code: 8541430000

Port: Shanghai,Guangzhou,Ningbo

Payment Type: L/C,T/T

Incoterm: FOB,CFR,CIF,EXW,FCA,CPT,CIP

Packaging & Delivery

Selling Units:Watt/WattsPackage Type:Standard Exported Pallet

Product Showcase

20240418135944 Png
20240419131601 Png

Product Description

Double Glass Bifacial 144cells Solar Panel 455W

Mechanical Specifications		working Conditions
solar Cells	166mm(144HC)	Maximum System Voltage(V)	1000/1500Vdc (IEC/UL)
Dimensions	2108104835mm	Maximum Series Fuse Rating (A)	25A
Weight	23.5kg	Operating Temperature	-40~+85℃
Front Cover	3.2 mm thick, tempered glass	Power Tolerance(W)	(0,+4.99)
back Cover	TPT(Tedlar-PET-Tedlar)	Output Cables	4.0 mm2,Cable length:500 mm
Encapsulation Material	EVA(Ethylene Vlinyl acetate)	Connector	MC4 Compatible
Frame	Anodized aluminum alloy	Mechanical Load	Front Side Max.5400 Pa, Rear Side Max. 2400 Pa
Frame Color	Silvery	Junction Box	IP68

Module type	455M6-24
Maximum Power (Pmax)	455W
Open Circuit Voltage (Voc)	49.85V
Short Circuit Current (Isc)	11.41A
Max. Power Voltage (Vm)	41.82V
Max. Power Current (Im)	10.88A
Temperature coefficients of Isc (%)	0.057/℃
Temperature coefficients of Voc (%)	-0.270/℃
Temperature coefficients of Pm (%)	-0.350/℃
Module Efficiency (%)	≥20.60%
